1. Product Induction
XBC-l type Single-suction multi-stage sectional vertical fire pump for conveying water without solid particles and the physical and chemical properties similar to water in the liquid, it is mainly used for pressurized water supply in fire control system, can also be applied to industrial water supply and drainage. Its performance and technical conditions in accordance with national new GB6245-1998 standard for fire pump performance requirements and test methods of the requirements, product by the national fire equipment quality supervision and test center testing qualified, certificate by the Shanghai fire control products.
2. Range Of Application
A. Compact structure, small volume, beautiful appearance, small installation space, its center of gravity coincidence in the center of pump foot, enhances the running stability and service life of pump.
B. The pump suction and discharge nozzles are horizontal, which has simplified the connection of pipeline.
C. According to the needs, the suction and discharge nozzles can be installed into the same direction or 90 °, 180 °, 270 ° several different direction in order to meet different connection.
D. Pump pressure according to the need to increase or decrease the pump series and cutting impeller diameter and meet, without changing the installation area, and this is what other pumps.
